CROSSFIRE CF50
GET A QUOTE FOR A CROSSFIRE CF50
The Crossfire CF50 was engineered ground up with weight, height and handling in mind. For our smallest riders we have used the lightest materials. These include aluminium wheels and hubs, aluminium engine case and cylinder head and forged triple clamps and risers.
We were aiming for the lightest 4 stroke bike we can make. The result was a 46kg dry weight. This means the bike will be easier to handle easier to load and most importantly more manageable for the little champs riding them.
The centre mount battery for the electric start system is in the middle of the bike keeping weight distribution to closer to 50:50 more importantly starting the bike is just a matter of pushing the e-start button.
The bike has a throttle limiter on the twist throttle. Although the bike will eventually accelerate to speed any way it stops the kids ability to pin the throttle all the way. It’s a fantastic aid we recommend this setup done by your authorised dealer.
We optioned the more powerful Hydraulic disc brakes as opposed to cable set up to increase power and reduce the force that’s needs by the kids to squeeze. Training wheels also available.
Product Dimensions: 1290mm x 680mm x 840mm
Seat height: 570mm
Fuel Capacity: 3 litres
Vehicle Weight: 46kg
Clearance: 170mm
Wheelbase: 920mm
Displacement: 50cc
Bore x Stroke: 44 x 37.4mm
Compression ratio: 8.5:1
Power Max: 5HP 7500rpm
Torque Max: 3Nm 4500rpm
Starting System: A9 Electric start
Gear box: Full automatic
Brakes Frt: 190mm disc
Brakes Rear: 190mm disc
Suspension Rear: 240mm dampened
Suspension Front: 39/42 – 550mm
Front: Steel rim 1.6-10 (2.50-10)
Rear: Steel rim 1.60-10 (2.50-10)
Available in Red, Blue, Green, White. Fully assembled, pre-delivered and ready for immediate use.
